| Product Parameter |
Parameter Description |
| Dimensions |
L80xW80xH40(mm) |
| Holding Force |
50kg(110Lbs) |
| Voltage |
Factory Default：24VDC，12VDC(Adjustment) |
| Current Draw |
12V/140mA 24V/70mA |
| Signal Output |
NO（ White）(YD-601S) |
| Suitable for |
All Kind of Single & Double Smokeproof Doors |
| Surface Temp |
≤+20℃ |
| Operating Temp |
-10～+55℃(14-131F) |
| Suitable Humidity |
0~90%(relative humidity) |
| Finishes for Shell |
High Temperature Paint and Environmental Protection Zinc |
| Finishes for Armature |
Zinc |
| Weight |
0.85kg |
| Certification |
CE-EMC FCC EN1155 EN1634-1 |
Col linear Load： 50kg（110pounds）.
Dual Voltage 12/24 VDC(Adjustable).
The Standard Voltage is 24VDC when Finished.
MOV Provides Reverse Current Protection.
Low Power,Environmental Protection.
Anti-Residual Magnetism Design.
Professional Design, Dual Insulate Housing.
Automatically close the smoke proof door when fire happens.
CE Certificate.
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
| Packing Quantity(PCS/CTN) |
20 |
| Packing Size(L*W*H)(cm) |
60*35*16.5 |
| Gross Weight(KG) |
17 |
