Product Parameter |
Parameter Description |
Dimensions |
75Lx80Wx63.05H(mm) |
Contact rating |
3A@36VDC |
Contact Output |
NO |
Material |
Zinc alloy housing |
Waterproof Level |
IP66 |
Operating temperature |
-10~+55℃(14-131F) |
Durability test |
100,000 tested |
Accessory |
M16x1.5(4-8) Explosion-proof cable plug |
Weight |
0.4kg |
Certification numbe |
ECM 23 ATEX-B DN 89 |
ATEX |
II 1G Ex ib IIC T6 Gb II 2D Ex ib IIIC T85°C /T100°C Db |
Explosion-proof anticorrosive push button, with increased safety structure, the housing is made of zinc alloy material by die-casting, the button is made of metal material, with corrosion resistance, high strength, beautiful appearance, equipped with wiring terminals
Application environment: explosive gas environment and dust environment
Applicable place: It is used for the position of fire passage in the dangerous area of explosive gas environment, used with explosion-proof access control products
Installation method: Surface mount, connect to the explosion-proof box and safety zone through the explosion-proof iron pipe and explosion-proof hose
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
