Product Parameter |
Parameter Description |
Feature |
Mortise mount |
Dimensions |
76Lx91 Wx46H(mm) |
Contact Rating |
200mA/24VDC (max) |
Voltage |
5-24VDC |
Open Wire |
White |
Contact |
NO |
Mechanical life |
100,000 tested |
LED |
Green when energized |
Structure |
Zinc alloy material, metal button |
Surface Treament |
Zinc alloy with black paint treatment |
Operating temp |
-10~ +55(14-131F) |
Operating humidity |
0-95% (non- condensing) |
Waterproof Level |
IP-67 |
Weight |
0.4kg |
Stainless steel Panel with Elegant Style.
100000 Cycles tests.
IP68 waterproof design,dustproof
Many Kinds of Colour, Applicable to and the Place.
Three Contact Output,Suitable for all kinds of Locks.
The Best Choice for Access Control.
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
