Product Parameter |
Parameter Description |
Dimensions |
140Lx40Wx27H(mm) |
Input Voltage |
12~24VDC |
Current |
≤50mA |
Contact |
NO(Green),NC(Yellow),COM(White) |
Electric Performance |
1A@30VDC |
Lock Signal |
NC/COM/NO |
LED Status |
When NC and COM connect,LED shows green When NO and COM connect,LED shows red |
Operating temp |
-20~+50℃ |
Operating Humidity |
0-95% (relative humidity) |
Weight |
0.2kg |
Certification |
CE-EMC CE-LVD RoHS |
304 stainless steel.
Input Voltage: 12~24VDC
LED Status: When NC and COM connect,LED shows green; When NO and COM connect,LED shows red.
Lock Signal: NC/COM/NO
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
