| Product Parameter |
Parameter Description |
| Dimensions |
86Lx86Wx40.1H(mm) |
| Standard structure |
304 stainless steel panel with metal button |
| Current rating |
3A@36VDC Max |
| Output contact |
NO/NC/COM |
| Mechanical life |
500000 tested |
| Suitable for door |
All kinds of doors |
| Operating temp |
10～+55(14-131F) |
| Operating humidity |
0-95% (relative humidity) |
| Panel Material |
304 stainless steel panel with wiredrawing finish |
| Back box finish |
304 stainless steel panel with wiredrawing finish |
| Weight |
0.2kg |
| Certification |
CE-EMC CE-LVD FCC-VOC RoHS REACH WEEE |
Design with no Mechanical Bolt.
Aluminum Panel with Elegant Style.
With the Bottom Box, Easy to Install.
500000 Cycles tests.
Two Contact Output,Suitable for all kinds of Locks.
The Best Choice for Access Control.
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
| Packing Quantity(PCS/CTN) |
50 |
| Packing Size(L*W*H)(cm) |
52*22*36 |
| Gross Weight(KG) |
20.0 |
