Product Parameter |
Parameter Description |
Size |
86Lx86Wx12H(mm) |
Input |
12~24VDC |
Current |
≤60mA |
Output contact |
NO/NC/COM |
Contact rating |
1A 24VDC |
LED Status |
Red: Standby Green : Operation |
Material for Cover Plate |
Tempered glass with mirror treatment |
Detection range |
5~20cm (Adjustable) |
Operating temp |
-20℃~+50℃(14-131F) |
Weight |
0.2kg |
Certification |
CE-LVD REACH |
Design without Mechanical Bolt
Stainless steel Panel with Elegant Style
Tested to 100,000 Cycles
Three Contact Output,Suitable for
all kinds of locks
The Best Choice of Access Control
